Case 1

What is the abnormality in this CXR?

Answer

Case 1 answer

Note the left lung is hyperluscent compared to right.

.What are your considerations?.

Answer

Case 1 answer

Unilateral hyperlucency can be seen in

• Compensatory hyperinflation
• Swyer James syndrome
• Ball valve occlusion of main stem bronchus
• Pleural effusion in supine position
• Agenesis of Pulmonary artery
• Pneumothorax
• Bullous disease
• Mastectomy or absent Pectorals

What do you think this case is and why do you say so?

Answer

Case 1 answer

Compensatory hyperinflation of Left lower lobe following resection of left upper lobe.

Note the position of left hilum, moved way up indicating that there has been loss of  lung volume in upper chest.

Look for rib resection, as evidence for prior Surgery (Not present in this case).

You should be aware of the criteria to diagnose the other listed conditions.

Select the next Case
